Atomstack A5 PRO 40W Laser Engraver

‚ā¨309,99 ‚ā¨249,99 SAVE ‚ā¨60,00
ūüéĀ Ships within 24-48 hours
ūüéĀ Delivery from EU warehouse, tax free

PLUG TYPE: EU Plug

EU Plug

SHIP FROM: EUROPE

EUROPE
  • Warranty:
    1-Year for New Machines

  • Shipping Time:
    Within 1-3 Days
    Shipping Policy >

  • International Express:
    3-5 Working Days

  • Liner Logistic:
    7-10 Working Days

paypalvisamasteramerican expressapple payklarna

Note: Customs duties will be incurred if your order is shipped from China.

Contact US: Whatsapp
Description

Notable Features:

1. Upgrated ultra-fine 0.23mm*0.23mm laser focal area
2. New eye protection design
3. 410x400mm large carving area
4. Upgraded high-quality laser
5. Full-metal structure
6. Quick assembly design
7. Precise scale lines

Specification:

Item Type

ATOMSTACK A5 PRO

Working Area

 410*400 mm

Engravable Materials

All wood, bamboo, paper, plastic, leather, PCB boards, aluminum oxide, non-reflective coated and lacquered metal, ceramics (should be painted black)

Cuttable Materials

Cardboard, non-woven fabric, balsa wood, acrylic material, thin plastic sheet.

Laser Electric Power

40W

Laser Output Power

5W-5.5W

Wave Length

445 ¬Ī 5nm

Engraving Accuracy

0.01mm

Laser Spot

 0.23mm*0.23mm

Focus Method

Fixed focus laser, no need to focus

Laser Protective Cover

Protect the user's eyes and prevent pets from grabbing the laser spot.

Operating Software

LaserGRBL (Windows), LightBurn (Windows & macOS)

File Type

NC, BMP, JPG, PNG, DXF, etc.

Data Transmission Method

USB connection.

Input Voltage

AC100-240V, 50/60Hz

Output Voltage

DC12V, 5A

Equipment Net Weight

4.0kg

Package Weight

5.2kg

Equipment Size

570*600*270mm

Packing Size

618*342*129mm

Certification

CE/FCC/RoHS/FDA/Weee



Feature:

1. New eye protection design: The Atomstack A5 Pro’s laser protective cover perfectly protects your eyes and filters 95% UV light. You and the people around can watch laser engraving without goggles, reducing the cost of your goggles and the inconvenience of wearing them.

2. Solid and easy installation structure design: The full-metal structure design makes the machine more solid, reduces machine vibration and improves engraving accuracy. The entire structure is designed for quick assembly, which can generally be completed within 10-20 minutes.

3. Fixed-focus laser: No need to rotate lens to focus. The laser focal length of is a fixed value, so move the lens up and down close to the surface of the object to start engraving.

4. High-energy, ultra-fine laser: The laser power is 5W-5.5W and the focal area of the ultra-fine laser is reduced to 0.23mm^2. The high-density laser can easily cut 12mm thick balsa wood and black acrylic. It can engrave smooth stainless steel metal and ceramics well.

5. Wide compatibility: Atomstack A5 Pro is compatible with various mature engraving software such as LaserGRBL and LightBurn, supporting Win XP / Win 7 / Win 8 / XP / Win 10, and MACs system (LightBurn), The engraving file format supports NC, BMP, JPG, PNG, DXF, etc.

6. Precise scale lines axis: There are precise scale lines on the X-axis and Y-axis to facilitate quick length measurement. 410x400mm large area engraving interval can meet your various engraving needs.

7. Integrated stepper motor and shaft: The machine uses an integrated lead screw rod instead of a combined coupling. The stepping motor and the screw rod are integrally formed, making the laser movement more precise and the coupling more durable.

Note:

1. When operating the laser engraving machine, please install the laser protective cover. If not installed, goggles will be required.
2. Please do not touch the laser emitter with your hands, otherwise it may burn your hands.
3. Please avoid strong impact on the machine.
4. Children under 14 are not allowed to use this product, and children over 14 need adult supervision.
5. The light engraving machine cannot be directly applied to any mirror-reflected objects, which may cause injury to the operator or burn the laser.

Package Included:

1 x X-axis assembly
2 x Section 57CM
2 x Section 48CM
1 x Control box
3 x Support legs
1 x Goggles
1 x Laser
1 x 24V2A power adapter
1 x Power cord
1 x USB cable

Step 1~5 Installation package

1 x M5 wrench
10 x Rolled belt
3 x Small wood
1 x focal length film
1 x M3 wrench
1 x Marker
1 x Brush
3 x Small acrylic

Details:
